NEW WORLD-B Series Adjustable roll to square bottom paper bag making machine

home/products/纸袋机

NEW WORLD-B Series Adjustable roll to square bottom paper bag making machine

纸袋机 Product Application:

NEW WORLD-B series  it uses paper roll in blank or printed as raw material, consists of automatic centre forward glue, printing tracking, fixed length and cutting, bottom indentation, folding bottom, bottom glue. This machine really realized the full automation production, can effectively save the labor cost.

Download DOC

Model New world -B220 New world -B330 New world -B400
New world -B460
New world -B550
Paper bag length 191-430mm 280-510mm 280-600mm
300-770mm


300-770mm


Paper bag width 80-200mm 150-330mm 150-400mm
220-460mm


260-550mm


Paper bag bottom width 50-120mm 70-150mm 90-200mm
90-260mm


900-260mm


Paper thickness 50-140g/m2 60-140g/m2 70-140g/m2
70-150g/m2


80-150 g/m2


Machine Speed 30-250pcs/min 30-200pcs/min 30-200pcs/min
30-150pcs/min
30-150pcs/min
Paper bag speed 100-180 pcs/min 100-160 pcs/min 100-160 pcs/min
60-120 pcs/min
60-120 pcs/min
Paper roll width 290-630mm 470-990mm 510-1230mm
650-1470mm


730-1650mm


Roll paper diameter 1500mm 1500mm 1500mm
1500mm
1500mm
Machine power 3 Phase  3 Phase  3 Phase
3 Phase
3 Phase
9kw 11kw 15.5kw
25kw
27kw
Machine weight 5600kg 8000kg
8000kg 12000kg
13000kg
Machine size 8600×2600×1900 mm 9500×2600×1900 mm
9500×2600×1900 mm 12000×4000×2000 mm
13000×2600×2000 mm


Full Machine Servo Motor Structure








SALES AND SERVICE NETWORK
FAQ
Q1:What kind of this machine can making ?
A1:This machine is mainly for square bottom papaer bag.
Q2:Is the bag size adjustable?
A2:The bag size is adjustable within machine size range.
Q3:what is the packing of the delivery?
A3:Wooden packing.
Q4:How many container we need for this machien ?
A4:According diffent machien size ,machine may loaidng up to 9m in container.
Q5:How to doing the after service?
A5:We support machine working manual,machine install and running video.Support the technician to install and guildance.
